The all-in-one advantage
for arterial thrombectomy
Artix™
Thrombectomy
System
All Clots*     •     One System     •     Don't Settle
Download Product Overview
Purpose-Built for Arterial
Developed from a true clinical need and shaped by direct physician feedback, Artix is a powerful, dual mechanical + aspiration solution, designed to address a broad spectrum of arterial thrombus cases.
Artix Thrombectomy System
Exceptional Treatment
Flexibility & Control
  • Dual mechanical thrombectomy + aspiration toolkit designed to remove acute to chronic clots*
  • Low profile, trackable, kink-resistant sheath expands treatment options
  • Over-the-wire mechanical element ensures complete access and precise control
  • Covered funnel catheter provides proximal flow restriction to reduce the risk of clot migration**
Artix System Components
Artix Thin-Walled
Sheath
Artix MT Mechanical
Thrombectomy Device
Covered Funnel
Catheter
Artix AX Aspiration
Catheter
Artix Thin-Walled Sheath
Aspiration-capable, ultralow profile
hydrophilic, 8 Fr
Enhanced trackability
and kink resistance
for an up-and-over
arterial thrombectomy
approach

2 lengths expand
treatment flexibility
65 cm and 90 cm
Hydrophilic coating
for smooth insertion
Terumo Destination
7 Fr
Artix Sheath
8 Fr
Terumo Destination
8 Fr
Same OD
Same ID
Tab Image 1
Artix MT Mechanical
Thromboectomy Device
Broad Treatment Range
2 sizes increase options for above and
below the knee thrombus
3-6 mm vessels
4-8 mm vessels
Internal struts
promote even distribution
of clot within the element
Distal segment
expands for seamless
cleaning of element
Variable cell structure
effectively collects and retrieves
acute-to-chronic clot
Offset mouth for
optimized clot capture
Covered Funnel Catheter
Ultimate Control
Covered nitinol mesh funnel is designed
to minimize the risk of arterial migration*
compresses clot into catheter to
improve clot retrieval
Covered nitonol funnel
catheter
ArtixThin-Walled Sheath
*According to benchtop testing compared to control. Internal data on file.
Note: To attempt to minimize risk of arterial embolization of blood clots, use of a device that entraps clots may potentially be helpful, but this has not yet been demonstrated to be effective in the arterial system.
Artix MX Aspiration
Catheter
8 Fr beveled tip
2 lengths treat vessels ≥ 3 mm
85 cm and 115 cm
Aspiration Flow Rates (cc/s)*
The only thrombectomy system
with intraprocedural blood return
Penumbra Indigo®
CAT 8
Artix AX Catheter (8F)
with 0.035” wire
Artix Thin-Walled Sheath
with 0.035” wire
70% Faster Aspiration Flow Rates*
Artix flow rates outpace the competition, using the
Artix AX Aspiration Catheter or Artix Thin-Walled Sheath.
Tab Image 4
*Benchtop testing. Data on file. Artix thin-walled sheath vs. Penumbra Indigo CAT 8 continuous aspiration catheter (included catheter and 8’ tubing under continuous pump-based aspiration).
Don't Settle
Artix is a combined aspiration + mechanical solution that delivers control, versatility, and unmatched performance, setting the new standard for arterial thrombectomy.
*Designed to remove acute to chronic arterial clots. According to benchtop testing compared to control. Internal data on file. Narula et al. JACC 2020;72:2153-63
** According to benchtop testing compared to control. Internal data on file.

Note: To attempt to minimize risk of arterial embolization of blood clots, use of a device that entraps clots may potentially be helpful, but this has not yet been demonstrated to be effective in the arterial system.

Indications for Use:
The Artix Thin-Walled Sheath is indicated for (1) the non-surgical removal of emboli and thrombi from blood vessels, (2) injection, infusion, and/or aspiration of contrast media and other fluids into or from a blood vessel, (3) use as a conduit for endovascular devices, (4) use in facilitating the insertion and guidance of an intravascular catheter into a selected blood vessel. The funnel provides temporary vascular occlusion during these and other angiographic procedures. The Artix Thin-Walled Sheath is intended for use in the peripheral vasculature. The Artix MT Thrombectomy Device is indicated for (1) the non-surgical removal of emboli and thrombi from a blood vessel, (2) injection, infusion, and/or aspiration of contrast media and other fluids into or from a blood vessel. The Artix MT Thrombectomy Device is intended for use in the peripheral vasculature. The Artix AX Aspiration Catheter is indicated for (1) the non-surgical removal of emboli and thrombi from blood vessels, (2) injection, infusion, and/or aspiration of contrast media and other fluids into or from a blood vessel. The Artix AX Aspiration Catheter is intended for use in the peripheral vasculature. The FlowSaver Blood Return System is used with Inari Medical catheters and sheaths for autologous blood transfusion.

Review complete Instructions for Use, Indications for Use, Warnings, Precautions, Possible Adverse Effects and Contraindications prior to use of the product.

For all non-Inari products, please refer to manufacturer Instructions for Use/Intended Purpose for complete indications for use, contraindications, warnings and precautions.

Caution: Federal (USA) law restricts these devices to sale by or on the order of a physician. All trademarks are property of their respective owners.
